The GEPRC SPEEDX2 1404 3000KV is a compact FPV motor for 3–4-inch lightweight builds, supporting 2–4S power systems with a 160W maximum power rating.
GEPRC SPEEDX2 1404 3000KV FPV motor black
€15.32
On order: Delivery 4-5 working days.
The GEPRC SPEEDX2 1404 3000KV is a compact FPV motor for 3–4-inch lightweight builds, supporting 2–4S power systems with a 160W maximum power rating.
A compact, high-efficiency FPV motor built for lightweight 3–4-inch freestyle and racing builds.
The GEPRC SPEEDX2 1404 3000KV is a brushless FPV motor designed for 3–4-inch lightweight frames. Running on 2–4S (7.4–14.8V) power systems, it delivers up to 160W of maximum power in a 10.5g package. N52H magnets and NSK/NMB bearings underpin its 9N12P configuration for reliable power delivery in compact builds.
Features
- 9N12P configuration with N52H magnets and NSK/NMB bearing
- Single-strand copper winding
- 2–4S (7.4–14.8V) compatible; 12A ESC recommended (not included)
- Compact Ø18.2 × 13.8mm dimensions; 9 × 9mm (M2) mounting pattern
- 160mm, 26AWG motor wires included
Technical Specifications
- KV: 3000KV
- Maximum power: 160W
- Peak current: 10A (3″)
- Interphase resistance: 0.33Ω
- Input voltage: 7.4–14.8V (2–4S LiPo)
- Motor dimensions: Ø18.2 × 13.8mm
- Shaft diameter: Ø1.5mm; shaft protrusion: 4mm
- Mounting pattern: 9 × 9mm (M2)
- Weight: 10.5g (including wire)
F42-00645
