The Pilotix 1405 4800KV is a compact brushless motor for 2–3-inch FPV drone builds on a 4S power system, weighing 12.4g.
Brushless Motor Pilotix 1405 4800KV
€20.96
On order: Delivery 4-5 working days.
The Pilotix 1405 4800KV is a compact brushless motor for 2–3-inch FPV drone builds on a 4S power system, weighing 12.4g.
A lightweight brushless motor built for compact FPV drone frames running 2–3-inch propellers on 4S.
The Pilotix 1405 4800KV is a brushless motor designed for small FPV drone builds. Its 9S12P configuration and N52SH arc magnets deliver up to 288W peak power at 4S voltage, while the 12.4g total weight keeps the build light. The 14×5mm stator fits within a compact 19×17.4mm overall footprint, suitable for tight 2–3-inch frames.
Features
- N52SH arc magnets with 9S12P configuration for efficient power delivery
- Rated for 4S (16V) with 18A peak current and 288W maximum instantaneous power
- Compatible with 2–3-inch propellers
- 1.5mm shaft with 3mm protrusion for secure propeller mounting
- 24AWG 100mm silicone wire included for connection
- Low 12.4g weight including cable
Technical Specifications
- Motor size: 1405
- KV rating: 4800KV
- Stator size: 14 × L5mm
- Overall dimensions: 19 × L17.4mm
- Rated voltage: 4S (16V)
- Peak current: 18A
- Maximum instantaneous power: 288W
- Idle current at 10V: 0.7A
- Internal resistance: 125mΩ
- Shaft diameter: 1.5mm / protrusion: 3mm
- Silicone wire: 24AWG, 100mm
- Weight (including cable): 12.4g
