RadioMaster RC TX12 MKII CC2500 EdgeTX is a compact RC controller with CC2500 radio, X4 Hall-effect gimbals, 128×64 LCD, USB-C QC3 charging and JR-compatible module bay.
Radio Controller RadioMaster TX12 MKII CC2500 EdgeTX
€87.90
On order: Delivery 4-5 working days.
RadioMaster RC TX12 MKII CC2500 EdgeTX is a compact RC controller with CC2500 radio, X4 Hall-effect gimbals, 128×64 LCD, USB-C QC3 charging and JR-compatible module bay.
The RadioMaster RC TX12 MKII CC2500 is a compact radio controller running EdgeTX, designed for FPV drones and other RC models. It features a built-in CC2500 radio system, X4 Hall-effect gimbals, a monochrome LCD display and a rear JR-compatible module bay for expanded radio system support. Batteries are not included.
CC2500 Radio System
The integrated CC2500 module operates on 2.400–2.480 GHz and connects to compatible receivers. Supported protocols and channel count depend on the receiver in use, with up to 16 channels available.
X4 Hall-Effect Gimbals
The X4 Hall-effect gimbals deliver smooth and precise stick input without the wear associated with resistive potentiometers. Both Mode 1 and Mode 2 configurations are supported.
EdgeTX & Display
The controller ships with EdgeTX pre-installed and uses a 128 × 64 monochrome LCD for model management and settings. Firmware can be updated via USB, SD card, EdgeTX Buddy or EdgeTX Companion. An SD card is included.
Battery & Charging
The battery compartment accepts 2 × 18650 cells, 2 × 21700 cells or a compatible 2S LiPo (maximum LiPo dimensions: 74 × 60 × 22 mm). Built-in USB-C QC3 charging allows convenient in-controller charging of suitable batteries. Batteries are not included.
JR-Compatible Module Bay
The rear JR-compatible module bay accepts external radio modules, making it straightforward to add support for additional radio systems beyond the built-in CC2500.
Specifications
- Model: RadioMaster TX12 MKII
- RF chip: CC2500
- Operating frequency: 2.400–2.480 GHz
- Operating system: EdgeTX
- Control channels: Up to 16, receiver dependent
- Gimbals: X4 Hall-effect
- Control modes: Mode 1 and Mode 2
- Display: 128 × 64 monochrome LCD
- Operating voltage: 6.6–8.4V DC
- Working current: 180 mA at 8.4V
- Charging: USB-C QC3
- Module bay: JR-compatible
- Battery options: 2 × 18650, 2 × 21700 or compatible 2S LiPo (not included)
- Maximum LiPo dimensions: 74 × 60 × 22 mm
- Dimensions: 170 × 159 × 108 mm
- Weight: 363 g
- Firmware updating: USB, SD card, EdgeTX Buddy, EdgeTX Companion
- SD card: Included
Package Includes
- 1 × RadioMaster TX12 MKII Radio Controller
- 1 × Antenna
- 1 × USB-C cable
- 1 × Quick Start Guide
- 1 × Sticker
