HGLRC Petrel 75Whoop V2 1S FPV Frame

The FPV Frame HGLRC Petrel 75Whoop V2 1S is a compact 75mm CineWhoop frame designed for indoor FPV builds. The package includes the frame, canopy, mounting hardware, shock-absorbing balls and rubber battery bands.

Reinforced Frame

The upgraded V2 frame features a reinforced rib design that increases structural strength and improves resistance to impacts and falls during demanding flights.

Compact 75mm Layout

With a 75mm wheelbase and overall dimensions of 100mm × 100mm, the frame provides a compact platform for indoor FPV flying. The frame weighs 5.52g, while the frame and canopy together weigh 6.9g.

Component Mounting

The frame provides 25.5mm × 25.5mm flight controller mounting holes, Φ6 × 3mm motor mounting holes and support for 14mm cameras. Its motor mounting design supports SPECTER 0802, 1002 and 1003 series motors.

Flexible Battery Mounting

The battery is secured using the included black rubber bands. This mounting method supports batteries with different capacities and allows 1S or 2S batteries to be fitted.

Specifications

Brand: HGLRC

Model: Petrel 75 Whoop Indoor Frame

Version: V2

Drone type: CineWhoop

Material: Polycarbonate

Colour: Transparent gray

Wheelbase: 75mm

Frame size: 100mm × 100mm

Flight controller mounting holes: 25.5mm × 25.5mm

Motor mounting holes: Φ6 × 3mm

Camera compatibility: 14mm

Motor size: 0802

Supported motor series: SPECTER 0802/1002/1003

Frame weight: 5.52g

Frame and canopy weight: 6.9g

Supported battery system: 1S or 2S

Package Includes

1 × 75mm frame

1 × 75mm canopy

4 × M1.4*8 screws

2 × M2*4 screws

4 × M2*6.6 shock-absorbing balls

6 × black rubber bands
